amtm LED control and RT-AX-58U

[Southmad1977]

Led Control not working properly with AX58U. Wifi 2.4ghz and 5ghz does not turn not ON when LED are switched to ON manually or scheduled. I'm using the same script with all my Aimesh nodes and this router seems to be the only one acting weird. Led control from the Asus Web UI seems to works fine. Anyone having the same behavior?



[thelonelycoder]

Post the output of this command for LEDs when set to on and off:

nvram show | sort | grep '^led_\|ledg_\|AllLED'

Firmware version?



[Southmad1977]

Post the output of this command for LEDs when set to on and off:

nvram show | sort | grep '^led_\|ledg_\|AllLED'

Firmware version?

LEDs On:

size: 77442 bytes (119166 left)
AllLED=1
AllLED_brightness=255
led_2g_gpio=255
led_5g_gpio=255
led_all_gpio=255
led_ctrl_cap=4
led_disable=0
led_lan1_gpio=255
led_lan2_gpio=255
led_lan3_gpio=255
led_lan4_gpio=255
led_lan_gpio=255
led_logo_gpio=255
led_pwr_gpio=4134
led_usb3_gpio=255
led_usb_gpio=255
led_val=1
led_wan_gpio=4107
led_wan_normal_gpio=4096
led_wps_gpio=4134

LEDs OFF:

AllLED=0
AllLED_brightness=255
led_2g_gpio=255
led_5g_gpio=255
led_all_gpio=255
led_ctrl_cap=4
led_disable=1
led_lan1_gpio=255
led_lan2_gpio=255
led_lan3_gpio=255
led_lan4_gpio=255
led_lan_gpio=255
led_logo_gpio=255
led_pwr_gpio=4134
led_usb3_gpio=255
led_usb_gpio=255
led_val=1
led_wan_gpio=4107
led_wan_normal_gpio=4096

Firmware and AMTM version:

amtm 6.1 by thelonelycoder
RT-AX58U (armv7l) Kernel-4.19.183
FW-3004.388.9_2-gnuto.. @ 192.168.1.5
Operation Mode: Repeater/AiMesh Node
Wed Jul 9 09:59:13 DST 2025



[Southmad1977]

LEDs On:

size: 77442 bytes (119166 left)
AllLED=1
AllLED_brightness=255
led_2g_gpio=255
led_5g_gpio=255
led_all_gpio=255
led_ctrl_cap=4
led_disable=0
led_lan1_gpio=255
led_lan2_gpio=255
led_lan3_gpio=255
led_lan4_gpio=255
led_lan_gpio=255
led_logo_gpio=255
led_pwr_gpio=4134
led_usb3_gpio=255
led_usb_gpio=255
led_val=1
led_wan_gpio=4107
led_wan_normal_gpio=4096
led_wps_gpio=4134

LEDs OFF:

AllLED=0
AllLED_brightness=255
led_2g_gpio=255
led_5g_gpio=255
led_all_gpio=255
led_ctrl_cap=4
led_disable=1
led_lan1_gpio=255
led_lan2_gpio=255
led_lan3_gpio=255
led_lan4_gpio=255
led_lan_gpio=255
led_logo_gpio=255
led_pwr_gpio=4134
led_usb3_gpio=255
led_usb_gpio=255
led_val=1
led_wan_gpio=4107
led_wan_normal_gpio=4096

Firmware and AMTM version:

amtm 6.1 by thelonelycoder
RT-AX58U (armv7l) Kernel-4.19.183
FW-3004.388.9_2-gnuto.. @ 192.168.1.5
Operation Mode: Repeater/AiMesh Node
Wed Jul 9 09:59:13 DST 2025

Same logs when LEDs are on and off from the Web UI:

ON:
AllLED=1
AllLED_brightness=255
led_2g_gpio=255
led_5g_gpio=255
led_all_gpio=255
led_ctrl_cap=4
led_disable=0
led_lan1_gpio=255
led_lan2_gpio=255
led_lan3_gpio=255
led_lan4_gpio=255
led_lan_gpio=255
led_logo_gpio=255
led_pwr_gpio=4134
led_usb3_gpio=255
led_usb_gpio=255
led_val=1
led_wan_gpio=4107
led_wan_normal_gpio=4096

OFF:

size: 77457 bytes (119151 left)
AllLED=0
AllLED_brightness=255
led_2g_gpio=255
led_5g_gpio=255
led_all_gpio=255
led_ctrl_cap=4
led_disable=0
led_lan1_gpio=255
led_lan2_gpio=255
led_lan3_gpio=255
led_lan4_gpio=255
led_lan_gpio=255
led_logo_gpio=255
led_pwr_gpio=4134
led_usb3_gpio=255
led_usb_gpio=255
led_val=0
led_wan_gpio=4107
led_wan_normal_gpio=4096
led_wps_gpio=4134



[thelonelycoder]

Same logs when LEDs are on and off from the Web UI:

ON:
AllLED=1
AllLED_brightness=255
led_2g_gpio=255
led_5g_gpio=255
led_all_gpio=255
led_ctrl_cap=4
led_disable=0
led_lan1_gpio=255
led_lan2_gpio=255
led_lan3_gpio=255
led_lan4_gpio=255
led_lan_gpio=255
led_logo_gpio=255
led_pwr_gpio=4134
led_usb3_gpio=255
led_usb_gpio=255
led_val=1
led_wan_gpio=4107
led_wan_normal_gpio=4096

OFF:

size: 77457 bytes (119151 left)
AllLED=0
AllLED_brightness=255
led_2g_gpio=255
led_5g_gpio=255
led_all_gpio=255
led_ctrl_cap=4
led_disable=0
led_lan1_gpio=255
led_lan2_gpio=255
led_lan3_gpio=255
led_lan4_gpio=255
led_lan_gpio=255
led_logo_gpio=255
led_pwr_gpio=4134
led_usb3_gpio=255
led_usb_gpio=255
led_val=0
led_wan_gpio=4107
led_wan_normal_gpio=4096
led_wps_gpio=4134

Are all the LEDs off when done trough the WebUI?



[Southmad1977]

Are all the LEDs off when done trough the WebUI?

Yes when I turn the switch OFF in the WebUi. And back on (including the 2.4 a 5ghz) when I switch them ON.

Below the whole log (First ON, then OFF)

ASUSWRT-Merlin RT-AX58U_V2 3004.388.9_2-gnuton1 Tue Jun 24 20:19:34 UTC 2025
admin2@RT-AX58U-0FC8:/tmp/home/root# nvram show | sort | grep '^led_\|ledg_\|AllLED'
size: 77457 bytes (119151 left)
AllLED=1
AllLED_brightness=255
led_2g_gpio=255
led_5g_gpio=255
led_all_gpio=255
led_ctrl_cap=4
led_disable=0
led_lan1_gpio=255
led_lan2_gpio=255
led_lan3_gpio=255
led_lan4_gpio=255
led_lan_gpio=255
led_logo_gpio=255
led_pwr_gpio=4134
led_usb3_gpio=255
led_usb_gpio=255
led_val=1
led_wan_gpio=4107
led_wan_normal_gpio=4096
led_wps_gpio=4134
admin2@RT-AX58U-0FC8:/tmp/home/root# nvram show | sort | grep '^led_\|ledg_\|AllLED'
size: 77457 bytes (119151 left)
AllLED=0
AllLED_brightness=255
led_2g_gpio=255
led_5g_gpio=255
led_all_gpio=255
led_ctrl_cap=4
led_disable=0
led_lan1_gpio=255
led_lan2_gpio=255
led_lan3_gpio=255
led_lan4_gpio=255
led_lan_gpio=255
led_logo_gpio=255
led_pwr_gpio=4134
led_usb3_gpio=255
led_usb_gpio=255
led_val=0
led_wan_gpio=4107
led_wan_normal_gpio=4096
led_wps_gpio=4134
admin2@RT-AX58U-0FC8:/tmp/home/root#
