Port forwarding not working - ASUS RT-AC68U

  • ATTENTION! As of November 1, 2020, you are not able to reply to threads 6 months after the thread is opened if there are more than 500 posts in the thread.
    Threads will not be locked, so posts may still be edited by their authors.
    Just start a new thread on the topic to post if you get an error message when trying to reply to a thread.

kaizenkid2000

New Around Here
I have followed tutorials on using my ASUS RT-AC68U and TPLink routers to connect to my non CGNAT modem to port forward. I have tested multiple ports and called ISP to verify they don't block but no avail. What I followed was this - https://www.noip.com/support/knowledgebase/setting-port-forward-asus-router/ - and have found tutorials saying that issue may be nothing is "listening to port" or no services connected to port and that is why it is showing as closed on https://canyouseeme.org/. Have verified and am using right IP's + tested switching off router firewall



Screenshots:




https://paste.pics/fd1519081f9d8e05edeff3f440d17493

Any help / common mistakes it I may be making appreciated. Apologies for spelling, english is not first language ;)


Justinh

Regular Contributor
Does your ISP block that port?
Is the device at 192.168.1.18 listening to that port? (Is there an app or service listening on that port?)
Does the network that the remote device is on block that port? (e.g., my company's network blocks almost all ports)

Last edited:

kaizenkid2000

New Around Here
Does your ISP block that port?
Is the device at 192.168.1.18 listening to that port? (Is there an app or service listening on that port?)
Called ISP verfied not blocked. Not sure how to get something listening as just wanted to check if port forwarding worked / is there a way to get something listening just to show it works + get back my sanity haha. As port checking sites show it's closed.


Justinh

Regular Contributor
Running a web server is pretty simple; you can listen on the default port 80 (and change your router mapping) or configure it to listen on 3030.

You also need to make sure the local device firewall is not blocking that port (for whatever application you listen with).

(Sorry for the redundant question about the ISP.)


Justinh

Regular Contributor
Just found some Windows apps for this kind of testing:


kaizenkid2000

New Around Here
Just found some Windows apps for this kind of testing:
Last question I promise haha, do I have to connect device to router via ethernet or can port forwarding be performed from a wirelessly connected windows laptop?


Justinh

Regular Contributor
Shouldn't matter. The mapping is based on IP address, not connection technology.

Last edited:

toaruScar

Regular Contributor
Can devices in your LAN other than the one with IP of 192.168.1.18 access port 3030 by connecting to 192.168.1.18:3030?
Does your ISP assign public IP to your router?
