VPNMON VPNMON-R3 v1.7.0 -Sep 20, 2025- Monitor OpenVPN/Wireguard WAN/Dual-WAN Health & Random Reset Multiple Connections (Available in AMTM!) - v1.8.0 Beta2

I think this is right.
The order of operations matters here — trying to disable monitoring after the fact is too late. Discovered this by doing it the wrong way first, then restoring again. (Only for the second go-round, monitoring had already been disabled by me.)

Thanks guys!!!!!
Just kill the script before doing any VPN/WG major slot work in the UI. Make sure it's not running. That's the simplest answer. 👍

Seeking feedback... I've been wanting to add an indicator showing how busy a certain connection was, and borrowed some functionality from RTRMON. Initially it was just a colored block (green/yellow/red) indicating bandwidth being consumed, but since I was getting actual numbers, I decided to just use them. I'm now wondering... is seeing incoming Mbps enough, or shall I just get it over with, sacrifice a little more screen space and show outgoing Mpbs as well?


Last edited:
Seeking feedback... I've been wanting to add an indicator showing how busy a certain connection was, and borrowed some functionality from RTRMON. Initially it was just a colored block (green/yellow/red) indicating bandwidth being consumed, but since I was getting actual numbers, I decided to just use them. I'm now wondering... is seeing incoming Mbps enough, or shall I just get it over with, sacrifice a little more screen space and show outgoing Mpbs as well?

View attachment 68144
I think it would be a great addition to vpnmon. If your gonna paint a picture why stop halfway. 😊

is seeing incoming Mbps enough, or shall I just get it over with, sacrifice a little more screen space and show outgoing Mpbs as well?
Download would be generally more useful for me but if you can squeeze them both in why not?

:D

Here's an early VPNMON-R3 beta... this update just contains the UI change indicating connection speed over the course of the timer. Please let me know if you see any inconsistencies!

What's new!?
v1.8.0b2 - (October 2, 2025)
- MINOR:
Added more visibility to the main UI, and included both TX and RX stats for each connection. Please know, these stats are basically the average connection speed across the length of the timer. They may not be entirely 100% accurate, and are a close approximation of the speeds encountered during this period of time. At the moment, the ranges for Green = 0 - 100Mbps, Yellow = 100 - 250Mbps, Red = > 250Mbps. Config menu item #14 allows you to modify these values based on your own personal preferences and bandwidth.
- PATCH: Fixed a few small inconsistencies across the script.

Download link:
Code:
curl --retry 3 "https://raw.githubusercontent.com/ViktorJp/VPNMON-R3/develop/vpnmon-r3.sh" -o "/jffs/scripts/vpnmon-r3.sh" && chmod 755 "/jffs/scripts/vpnmon-r3.sh"

Significant Screenshots:






Last edited:
I might be confused, Sould the TX showing on my vpn1 slot be RX.

VPNMON-R3 - v1.8.0b1 (S)how/(H)ide Operations Menu Thu Oct 2 19:42:53 EDT 2025

Port | Mon | IFace | Health | WAN State | Public WAN IP | Ping-->WAN | RxMbps | TxMbps | City Exit / Uptime
-------|-----|--------|--------|--------------|-----------------|------------|--------|------------------------------------------
WAN0 | [X] | eth0 | [ OK ] | Active | xxx.xxx.xxx.xxx | [ 11.278] | [ 6] | [ 0] | Salem: 4d 11h:08m
WAN1 | [X] | [n/a] | [n/a ] | Inactive | [n/a] | [n/a] | [n/a ] | [n/a ] | [n/a]
-------|-----|--------|--------|--------------|-----------------|------------|--------|------------------------------------------

OpenVPN

Slot | Mon | Svrs | Health | VPN State | Public VPN IP | Ping-->VPN | RxMbps | TxMbps | City Exit / Time Connected
-------|-----|--------|--------|--------------|-----------------|------------|--------|------------------------------------------
VPN1 | [X] | [ 8] | [ OK ] | Connected | 45.130.83.25 | [ 16.573] | [ 0] | [ 5] | New York: 1d 01h:38m
VPN2 | [X] | [ 8] | [ OK ] | Connected | 173.239.240.9 | [ 15.470] | [ 0] | [ 0] | Edison: 2d 08h:27m
VPN3 | [ ] | [0000] | [n/a ] | Disconnected | [n/a] | [n/a] | [n/a ] | [n/a ] | [n/a]
VPN4 | [ ] | [0000] | [n/a ] | Disconnected | [n/a] | [n/a] | [n/a ] | [n/a ] | [n/a]
VPN5 | [ ] | [0000] | [n/a ] | Disconnected | [n/a] | [n/a] | [n/a ] | [n/a ] | [n/a]
-------|-----|--------|--------|--------------|-----------------|------------|--------|------------------------------------------

Wireguard

Slot | Mon | Svrs | Health | WG State | Public WG IP | Ping--->WG | RxMbps | TxMbps | City Exit / Time Connected
-------|-----|--------|--------|--------------|-----------------|------------|--------|------------------------------------------
WGC1 | [X] | [ 2] | [ OK ] | Connected | 79.127.160.188 | [ 21.737] | [ 0] | [ 0] | Boston: 2d 08h:26m
WGC2 | [X] | [ 2] | [ OK ] | Connected | 79.127.160.194 | [ 21.126] | [ 0] | [ 0] | Boston: 2d 08h:25m
WGC3 | [ ] | [0000] | [n/a ] | Disconnected | [n/a] | [n/a] | [n/a ] | [n/a ] | [n/a]
WGC4 | [ ] | [0000] | [n/a ] | Disconnected | [n/a] | [n/a] | [n/a ] | [n/a ] | [n/a]
WGC5 | [ ] | [0000] | [n/a ] | Disconnected | [n/a] | [n/a] | [n/a ] | [n/a ] | [n/a]
-------|-----|--------|--------|--------------|-----------------|------------|--------|------------------------------------------


Attachments

  • Screenshot 2025-10-02 195735.png
    Screenshot 2025-10-02 195735.png
    176.3 KB · Views: 3
I might be confused, Sould the TX showing on my vpn1 slot be RX.

VPNMON-R3 - v1.8.0b1 (S)how/(H)ide Operations Menu Thu Oct 2 19:42:53 EDT 2025

Port | Mon | IFace | Health | WAN State | Public WAN IP | Ping-->WAN | RxMbps | TxMbps | City Exit / Uptime
-------|-----|--------|--------|--------------|-----------------|------------|--------|------------------------------------------
WAN0 | [X] | eth0 | [ OK ] | Active | xxx.xxx.xxx.xxx | [ 11.278] | [ 6] | [ 0] | Salem: 4d 11h:08m
WAN1 | [X] | [n/a] | [n/a ] | Inactive | [n/a] | [n/a] | [n/a ] | [n/a ] | [n/a]
-------|-----|--------|--------|--------------|-----------------|------------|--------|------------------------------------------

OpenVPN

Slot | Mon | Svrs | Health | VPN State | Public VPN IP | Ping-->VPN | RxMbps | TxMbps | City Exit / Time Connected
-------|-----|--------|--------|--------------|-----------------|------------|--------|------------------------------------------
VPN1 | [X] | [ 8] | [ OK ] | Connected | 45.130.83.25 | [ 16.573] | [ 0] | [ 5] | New York: 1d 01h:38m
VPN2 | [X] | [ 8] | [ OK ] | Connected | 173.239.240.9 | [ 15.470] | [ 0] | [ 0] | Edison: 2d 08h:27m
VPN3 | [ ] | [0000] | [n/a ] | Disconnected | [n/a] | [n/a] | [n/a ] | [n/a ] | [n/a]
VPN4 | [ ] | [0000] | [n/a ] | Disconnected | [n/a] | [n/a] | [n/a ] | [n/a ] | [n/a]
VPN5 | [ ] | [0000] | [n/a ] | Disconnected | [n/a] | [n/a] | [n/a ] | [n/a ] | [n/a]
-------|-----|--------|--------|--------------|-----------------|------------|--------|------------------------------------------

Wireguard

Slot | Mon | Svrs | Health | WG State | Public WG IP | Ping--->WG | RxMbps | TxMbps | City Exit / Time Connected
-------|-----|--------|--------|--------------|-----------------|------------|--------|------------------------------------------
WGC1 | [X] | [ 2] | [ OK ] | Connected | 79.127.160.188 | [ 21.737] | [ 0] | [ 0] | Boston: 2d 08h:26m
WGC2 | [X] | [ 2] | [ OK ] | Connected | 79.127.160.194 | [ 21.126] | [ 0] | [ 0] | Boston: 2d 08h:25m
WGC3 | [ ] | [0000] | [n/a ] | Disconnected | [n/a] | [n/a] | [n/a ] | [n/a ] | [n/a]
WGC4 | [ ] | [0000] | [n/a ] | Disconnected | [n/a] | [n/a] | [n/a ] | [n/a ] | [n/a]
WGC5 | [ ] | [0000] | [n/a ] | Disconnected | [n/a] | [n/a] | [n/a ] | [n/a ] | [n/a]
-------|-----|--------|--------|--------------|-----------------|------------|--------|------------------------------------------
Yes... Nice catch. Let me look into that!

I might be confused, Sould the TX showing on my vpn1 slot be RX.

VPNMON-R3 - v1.8.0b1 (S)how/(H)ide Operations Menu Thu Oct 2 19:42:53 EDT 2025

Port | Mon | IFace | Health | WAN State | Public WAN IP | Ping-->WAN | RxMbps | TxMbps | City Exit / Uptime
-------|-----|--------|--------|--------------|-----------------|------------|--------|------------------------------------------
WAN0 | [X] | eth0 | [ OK ] | Active | xxx.xxx.xxx.xxx | [ 11.278] | [ 6] | [ 0] | Salem: 4d 11h:08m
WAN1 | [X] | [n/a] | [n/a ] | Inactive | [n/a] | [n/a] | [n/a ] | [n/a ] | [n/a]
-------|-----|--------|--------|--------------|-----------------|------------|--------|------------------------------------------

OpenVPN

Slot | Mon | Svrs | Health | VPN State | Public VPN IP | Ping-->VPN | RxMbps | TxMbps | City Exit / Time Connected
-------|-----|--------|--------|--------------|-----------------|------------|--------|------------------------------------------
VPN1 | [X] | [ 8] | [ OK ] | Connected | 45.130.83.25 | [ 16.573] | [ 0] | [ 5] | New York: 1d 01h:38m
VPN2 | [X] | [ 8] | [ OK ] | Connected | 173.239.240.9 | [ 15.470] | [ 0] | [ 0] | Edison: 2d 08h:27m
VPN3 | [ ] | [0000] | [n/a ] | Disconnected | [n/a] | [n/a] | [n/a ] | [n/a ] | [n/a]
VPN4 | [ ] | [0000] | [n/a ] | Disconnected | [n/a] | [n/a] | [n/a ] | [n/a ] | [n/a]
VPN5 | [ ] | [0000] | [n/a ] | Disconnected | [n/a] | [n/a] | [n/a ] | [n/a ] | [n/a]
-------|-----|--------|--------|--------------|-----------------|------------|--------|------------------------------------------

Wireguard

Slot | Mon | Svrs | Health | WG State | Public WG IP | Ping--->WG | RxMbps | TxMbps | City Exit / Time Connected
-------|-----|--------|--------|--------------|-----------------|------------|--------|------------------------------------------
WGC1 | [X] | [ 2] | [ OK ] | Connected | 79.127.160.188 | [ 21.737] | [ 0] | [ 0] | Boston: 2d 08h:26m
WGC2 | [X] | [ 2] | [ OK ] | Connected | 79.127.160.194 | [ 21.126] | [ 0] | [ 0] | Boston: 2d 08h:25m
WGC3 | [ ] | [0000] | [n/a ] | Disconnected | [n/a] | [n/a] | [n/a ] | [n/a ] | [n/a]
WGC4 | [ ] | [0000] | [n/a ] | Disconnected | [n/a] | [n/a] | [n/a ] | [n/a ] | [n/a]
WGC5 | [ ] | [0000] | [n/a ] | Disconnected | [n/a] | [n/a] | [n/a ] | [n/a ] | [n/a]
-------|-----|--------|--------|--------------|-----------------|------------|--------|------------------------------------------
So yeah... you were correct in your assessment. Looking at my RTRMON code, those values are actually reversed, even though I am pulling the right RX and TX values. They seem to be reversed at the source. I've made this change, and published Beta 2:

Code:
curl --retry 3 "https://raw.githubusercontent.com/ViktorJp/VPNMON-R3/develop/vpnmon-r3.sh" -o "/jffs/scripts/vpnmon-r3.sh" && chmod 755 "/jffs/scripts/vpnmon-r3.sh"

Please let me know if it looks better! Also, I've added a Config Menu item #14 that allows you to change these values to your own preferences. Thanks for taking a look!
